Specialized - Haul ST - Gloss White Mountains - ONE-SIZE
Specialized - Haul ST - Gloss White Mountains - ONE-SIZE
Whatever you’re into, get more into it with the Specialized Globe Haul ST. It’s down for the ride. With 419 pounds of cargo capacity (rider included) up to 60 miles at a time, this fully customizable electric bike has the speed, power, range, and stability to get you wherever you need to go with whatever you need. With a grip of mounting opportunities you can bring the kids, a kayak, and stop on the way home for groceries. Don’t sweat it getting dark on you either. Integrated front and rear lights will have you dialed from dawn patrol to golden hour.
POWERED UP. The rear hub motor will have you zooming up hills with all your gear. Need a little extra boost to make it through an intersection safely? Crank up the power to get up to top speed quick, then dial it back and hit the pedals for max range.
INCLUSIVE. All bodies, all fun. The unique single size frame fits riders comfortably all over the size spectrum. Using the Retül database, the adjustable fit was designed to be perfect for you. Make it longer here, shorter there, and you're ready to ride comfortably. The low center of gravity means it’s easy to handle for a newcomer or a pro, loaded up or loaded down.
READY TO ROLL. The Globe Haul ST is ready to rock straight out of the box with an included MIK-compatible rear rack, full coverage fenders, integrated lights and center stand. D.I.Y. yourself into gear-nirvana, with a whole host of Globe accessories compatible with the auxiliary mounting points… It’s your Globe, we’re just living in it.
700w rear hub motor delivers enough power to get you and all your gear up steep hills and all the way across town at top speed. The 772wh battery provides up to 60 miles of range at the lower levels of pedal assist.
419 lbs carrying capacity, rider included.
All rear racks have been updated to 132 lbs (60kg) max weight capacity - even those labeled ‘40kg’. So get Haulin’.
Unique, single-size frame fits riders from around 4’5” all the way up to 6'4". The telescoping seatpost has over 13 inches of adjustability, and the quill stem can extend almost six inches. It provides a comfortable ride to almost everyone measured in our Retül database.
20” diameter wheels help keep weight low to the ground for improved stability. The extra wide 3.5” Carless Whisper tires provide comfort and traction on any terrain and feature a 3-ply casing for superior flat protection.
A lifetime warranty on the frame, and two year e-system warranty will keep your bases covered. With the Specialized network of service centers and superior customer service, you’re never on your own.
Geometry
One Size | |
---|---|
Crank Length | 160mm |
Handlebar Width | 700mm |
Stem Length | 45mm |
Saddle Width | 200mm |
Seatpost Length | 585mm |
Reach | 345mm |
Head-Tube Length | 292mm |
Head-Tube Angle | 70° |
B-B Height | 285mm |
B-B Drop | 5mm |
Trail | 47mm |
Fork Length (full) | 372mm |
Fork Rake/Offset | 55mm |
Front-Center | 624mm |
Chain-Stay Length | 465mm |
Wheelbase | 1089mm |
Top-Tube Length (horizontal) | 600mm |
Bike Stand-Over Height | 511mm |
Seat-Tube Length | 366mm |
Seat-Tube Angle | 68° |
Stack | 610mm |
Seat height - Max | 852mm |
Seat height - Min | 517mm |
Bar height form ground - Max | 1192mm |
Bar height from ground - Min | 1051mm |
Technical Specifications
Technical Specifications
E-Bike
Motor
Globe custom tuned motor, alloy, 6-bolt disc, 9 speed freehub, bolt on, 36h
Battery
Globe external battery, 772Wh, IPX7
UI/Remote
Globe handlebar remote HMI, State of charge, Ride Mode display, USB plug, BLE
Charger
Globe charger, 48V System w/ Globe system charger plug, AC power cord included
Wiring Harness
Globe wiring harness, IP65
Frameset
Frame
Haul ST Premium Aluminum, Post mount disc brake, fender/rack mounts
Seat Binder
Alloy, Bolt-type, 39mm
Suspension
Fork
2022 Globe Fork
Brakes
Front Brake
Tektro HD-T535, 4 piston caliper, hydraulic disc, 203mm rotor
Rear Brake
Tektro HD-T535, 4 piston caliper, hydraulic disc, 203mm rotor
Drivetrain
Shift Levers
microSHIFT Advent, 9-speed
Rear Derailleur
microSHIFT, short cage, 9-speed
Cassette
SunRace, 9-Speed, 11-36t
Chain
KMC e9S EPT, anti-rust coating, 9-speed w/ reusable Missing Link™
Crankset
Forged alloy arm, alloy chainring guard, 160mm
Chainrings
50T
Bottom Bracket
Square-tapered, 100mm BB width, 184mm spindle, w/ torque sensor
Wheels & Tires
Rims
20'', double-wall alloy, 50X20mm, 36h
Front Hub
Alloy, 6-bolt disc, 110mm spacing, loose ball bearings, bolt on, 36h
Spokes
Stainless, 13g/2.3mm
Front Tire
Carless Whisper Reflect, 20X3.5
Rear Tire
Carless Whisper Reflect, 20X3.5
Inner Tubes
Schrader, 32mm valve
Cockpit
Stem
Globe, cargo 1.5X150mm quill stem
Handlebars
Globe, cargo, alloy, 12-degree backsweep, 80mm rise, 31.8mm. 700mm width
Grips
Globe closed end slip on type, 155mm
Saddle
Specialized Body Geometry Comfort Gel
SeatPost
Double Extension Seatpost +/- 330mm, 34.9mm, 585mm, 20mm Offset
Accessories
Pedals
Specialized Flat pedal
Headlight
Globe Cargo Drive, 1500 Lumen, remote switch, multiple modes.
Taillight
Globe Cargo Drive, 50 Lumen
Rack
Globe, Short Tail, MIK HD interface, rail system
Fenders
Globe Cargo fenders, w/headlight mount
Kickstand
Globe, Short Tail, center mount
Bell
Brass bell
Product Details
Product ID
277759
Compliance Certification
As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. For information on lithium-ion battery standards and regulations in New York City, visit: www.nyc.gov/fdny/batteries
Weight
Weight
35.0kg (77 lb, 2.6 oz)
Weight Size
One Size
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
