Specialized - Haul LT - Gloss White Mountains - ONE-SIZE
Specialized - Haul LT - Gloss White Mountains - ONE-SIZE
All the Haul features you love with an extended back end. The Haul LT delivers an increased carrying capacity and a rear rack twice the size so you can get more into it than ever before. Brand new accessory options available only on the LT make it more customizable, for whatever you need however you need it. It’s your specially designed tool to do it all… Is that your car breaking into a nervous sweat?
MORE POWER!: Loaded up or on the way to load up, you’ll be zipping around like a hummingbird with pedal assist. A 772 watt-hour battery with up to 60mi range, and a top speed of 28mph with more carrying capacity. What hill? Didn’t notice!
CARGO, CARGO, AND MORE CARGO: The extended back end - or Long Tail, get it? - on the LT means twice the accessory mounts. Throw on six panniers, 2 seats or a combo of both. New to the LT are customizable cargo rails and running boards for better passenger stability, more bags or a custom combo only you could dream up. With the right accessories you'll be prepared to ride the kids to soccer practice and still pick up groceries on the way. With the extra wide kickstand and 20” wheels your start, ride, and stop will be stable and smooth.
LIFEPROOF: We developed the Haul LT the same way we would a Tour de France winning race bike, and we back it up like one. The Haul LT is so well built that we back the frame up for life. Globe doesn’t make toys, we make tools for life that just happen to be a heck of a lot of fun. Made especially so you can get more into it.
Designed to tackle the biggest errands you can dream up with a 31 inch long, MIK-compatible rear rack and tons of additional accessory mounts along the frame and fork.
The extra-wide center stand helps make loading and unloading your cargo, up to 441 lbs of it (rider included), safe and easy.
LT rear racks have been updated to 176 lbs (80kg) max weight capacity - even those labeled ‘60kg’ – so get Haulin’.
The full-coverage fenders and rear wheel covers help keep you and your bike clean and debris out of your spokes.
700w rear hub motor delivers enough power to get you and all your gear up steep hills and all the way across town at up to 28 mph. The 772wh battery provides up to 60 miles of range.
Unique, single-size frame fits riders from around 4’5” all the way up to 6’4”. The telescoping seatpost has over 13 inches of adjustability, and the quill stem can extend almost 6 inches. It provides a comfortable ride for almost everyone measured in our giant Retül database.
20” diameter wheels help keep weight low to the ground for improved stability. The extra wide 3.5” Carless Whisper tires provide comfort and traction on any terrain and feature a 3-ply casing for superior flat protection.
A lifetime warranty on the frame, and 2 year e-system warranty will keep your bases covered. With the Specialized network of service centers and superior customer service, you’re never on your own.
Geometry -
One Size | |
---|---|
Crank Length | 160mm |
Handlebar Width | 700mm |
Stem Length | 45mm |
Saddle Width | 200mm |
Seatpost Length | 585mm |
Stack | 610mm |
Reach | 345mm |
Head-Tube Length | 292mm |
Head-Tube Angle | 70° |
B-B Height | 285mm |
B-B Drop | 5mm |
Trail | 47mm |
Fork Length (full) | 372mm |
Fork Rake/Offset | 55mm |
Front-Center | 624mm |
Chain-Stay Length | 732mm |
Wheelbase | 1356mm |
Top-Tube Length (horizontal) | 600mm |
Bike Stand-Over Height | 511mm |
Seat-Tube Length | 366mm |
Seat-Tube Angle | 68° |
Seat height - Max | 852mm |
Seat height - Min | 517mm |
Bar height form ground - Max | 1192mm |
Bar height from ground - Min | 1051mm |
Technical Specifications
Technical Specifications
E-Bike
Motor
Globe custom tuned motor, alloy, 6-bolt disc, 9 speed freehub, bolt on, 36h
Battery
Globe external battery, 772Wh, UL 2271 certified, IPX7
UI/Remote
Globe handlebar remote HMI, State of charge, Ride Mode display, USB plug, BLE
Charger
Globe charger, 48V System w/ Globe system charger plug, AC power cord included
Wiring Harness
Globe wiring harness, IP65
Frameset
Frame
Haul LT Premium Aluminum, Post mount disc brake, fender/rack mounts
Seat Binder
Alloy, Bolt-type, 39mm
Suspension
Fork
Globe Steel, Post mount disc brake, fender/rack mounts
Brakes
Front Brake
Tektro HD-T535, 4 piston caliper, hydraulic disc, 203mm rotor, E-Bike rated
Rear Brake
Tektro HD-T535, 4 piston caliper, hydraulic disc, 203mm rotor, E-Bike rated
Drivetrain
Shift Levers
microSHIFT Advent, 9-speed
Rear Derailleur
microSHIFT, short cage, 9-speed
Cassette
SunRace, 9-Speed, 11-36t
Chain
KMC e9S EPT, anti-rust coating, 9-speed w/ reusable Missing Link™
Crankset
Forged alloy arm, alloy chainring guard, 160mm
Chainrings
50T
Chaincase
Chain Guide, Upper Guard
Bottom Bracket
Square-tapered, 100mm BB width, 184mm spindle, w/ torque sensor
Wheels & Tires
Rims
20'', double-wall alloy, 50X20mm, 36h
Front Hub
Alloy, 6-bolt disc, 110mm spacing, loose ball bearings, bolt on, 36h
Spokes
Stainless, 13g front, 13g-12g butted rear
Front Tire
Globe Reflect, Tan Sidewall, 20x3.5
Rear Tire
Globe Reflect, Tan Sidewall, 20x3.5
Inner Tubes
Schrader, 32mm valve
Cockpit
Stem
Globe, cargo 35X150mm quill stem
Handlebars
Globe, cargo, alloy, 12-degree backsweep, 80mm rise, 31.8mm. 700mm width
Grips
Globe closed end slip on type, 155mm
Saddle
Specialized Body Geometry Comfort Gel
SeatPost
Telescoping, alloy, 2-bolt Clamp, 20mm offset, 34.9mm, 525mm
Accessories
Pedals
Specialized Body Geometry Fitness, platform, plastic
Headlight
Globe Cargo Drive, 1500 Lumen, remote switch, multiple modes.
Taillight
Globe Cargo Drive, 50 Lumen
Rack
Globe, Long Tail, MIK HD interface, rail system
Fenders
Globe Cargo fenders, w/headlight mount
Kickstand
Globe, Long Tail, extra-wide leg design, center mount
Bell
Specialized brass bell
Product Details
Product ID
277758
Compliance Certification
As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. For information on lithium-ion battery standards and regulations in New York City, visit: www.nyc.gov/fdny/batteries
Weight
Weight
40 kg (88 lb, 3.0 oz)
Weight Size
One Size
* Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
